Mercury Marine 300XL FourStroke DTS
Mercury Marine 300XL FourStroke DTS

Specs

General Information

Manufacturer
Mercury Marine
Mercury Marine
Model
300XL FourStroke DTS
300XL FourStroke DTS
Model Code
13000016A
13000016A
Color
Warm Fusion White
Warm Fusion White

Electrical

Alternator
85A (1,071W) with Idle Charge
85A (1,071W) with Idle Charge

Engine

Engine Type
V-8
V-8
Ignition
SmartCraft PCM 112 Digital Inductive
SmartCraft PCM 112 Digital Inductive
Starting
Electric Start with SmartStart Protection
Electric Start with SmartStart Protection
Exhaust
Through prop
Through prop

Measurements

Power
300 Horsepower
300 Horsepower
Displacement
4,600 Cubic Centimeter
4,600 Cubic Centimeter
Bore x Stroke
3.6 x 3.4 in. (92 x 86 mm)
3.6 x 3.4 in. (92 x 86 mm)
Shaft Length
25"
25"
Dry Weight
538 lbs
538 lbs

Operational

Steering

Hydraulic (standard)

Power (optional)

Hydraulic (standard)

Power (optional)

Fuel Type
Unleaded
Unleaded
Full Throttle RPM Range
5,200 - 6,000
5,200 - 6,000
Fuel Induction
Electronic Fuel Injection (EFI) Computer Controlled with Advanced Range Optimization
Electronic Fuel Injection (EFI) Computer Controlled with Advanced Range Optimization
Lubrication

Integrated wet sump

Recommended oil - NMMA Certified FCW SAE 10W-30

Oil capacity - 7.0 qt. (6.6 l)

Integrated wet sump

Recommended oil - NMMA Certified FCW SAE 10W-30

Oil capacity - 7.0 qt. (6.6 l)

Cooling
Water-cooled with thermostat
Water-cooled with thermostat
Gear Ratio
1.75:1
1.75:1
Gear Shift

F-N-R

Gearcase options - 5.44 in.

F-N-R

Gearcase options - 5.44 in.

Trim System

Power trim and tilt

Max. trim range - 20° (-6° to 14°)

Max. tilt range - 73° (-6° to 67°)

Power trim and tilt

Max. trim range - 20° (-6° to 14°)

Max. tilt range - 73° (-6° to 67°)

Instrumentation
Engine protection operator warning system - SmartCraft Engine Guardian
Engine protection operator warning system - SmartCraft Engine Guardian

Other

Additional Colors

Phamton Black

Pearl Fusion White

Phantom Black

Warm Fusion White

Phamton Black

Pearl Fusion White

Phantom Black

Warm Fusion White

Features

Features

  • CARB star rating - 3
  • Air induction - Performance-Tuned Long-Runner Intake Manifold
  • Recommended fuel - Unleaded Regular 87 Octane Mini-mum (R+M/2) or 90 RON 10% Ethanol Maximum
  • Controls - Digital Throttle & Shift (DTS)
  • Compatible with SmartCraft digital technology

FourStroke Advantage

  • COMFORT: With a balanced powerhead and sophisticated, vibration-dampening cowl design, Mercury FourStroke outboards deliver an exceptionally smooth and quiet ride at any speed.
  • DURABILITY: Premium corrosion-preventive technologies and durable components ensure FourStroke outboards can stand up to the most demanding marine environments.
  • COMPACT DESIGN: Ideal for new engine setups or repowers, the slender width of a Mercury FourStroke outboard fits most transoms, including those with narrow engine wells and tight motor spacing.
  • EFFICIENCY: Explore farther and stay out longer thanks to impressive power-to-weight ratios, intelligent fuel systems and optimized fuel injection (on most models) that maximize performance from every drop of fuel.

FourStroke Performance Data

  • EXCEPTIONALLY SMOOTH & QUIET: The V8 300hp FourStroke outboard is 33% quieter at cruise with 30% less transmitted vibration at idle than the leading four-stroke competitor.
  • HIGH DISPLACEMENT: The high-displacement, quad-cam design of the V8 FourStroke powerhead generates serious torque, especially at mid-range, for quick acceleration and exciting speeds.
  • LIGHT & COMPACT: The V8 300hp FourStroke outboard is the lightest in the 300hp class by more than 20 pounds. Both V8 models mount on 26-inch centers for easy repowers or new installation on a wide range of boats.

Intuitive, Innovative Features

  • ADAPTIVE SPEED CONTROL: The Adaptive Speed Control feature lets you maintain engine rpm despite changes in load or conditions. Climbing large swells is easier. Cruising at low speeds is smoother. Carving out tight turns is effortless.
  • SMOOTH AND QUIET: Featuring a large muffler and a vibration-dampening cowl design, Mercury V8 FourStroke outboards deliver an exceptionally smooth, quiet ride at any speed.
  • EASY TO MAINTAIN: The exclusive Top Cowl Service Door simplifies routine maintenance, letting you check or add engine oil without removing the top cowl. An hour-based maintenance schedule decal is located under the cowl, providing a quick overview of routine maintenance.
  • AMPLE CHARGING OUTPUT: A powerful alternator delivers 85 amps of charging power at wide-open throttle – perfect for keeping onboard electronics running long into the fun.
  • INDUSTRY-EXCLUSIVE BATTERY MANAGEMENT TECHNOLOGY: When needed, the idle charge battery management system works for you by monitoring battery voltage and adjusting engine rpm at idle to boost alternator output.

Warranty & Maintenance

  • WARRANTY COVERAGE: Mercury makes world-class marine products backed by world-class warranties.
  • MAINTENANCE: At Mercury, we make maintenance easy. Learn more about how to keep your Mercury products performing at their peak.
